Primix
BSP(F) Mixer
|
INSTALLATION LENGTH |
|||||
| SIZE |
NUMBER OF ELEMENTS |
||||
|
2 |
3 |
4 |
5 |
6 |
|
| DN15 / ½” |
123 |
148 |
173 |
198 |
223 |
| DN20 / ¾” |
141 |
176 |
211 |
246 |
281 |
| DN25 / 1″ |
175 |
220 |
265 |
310 |
355 |
| DN32 / 1¼” |
211 |
271 |
326 |
386 |
441 |
| DN40 / 1½” |
229 |
299 |
364 |
429 |
494 |
| DN50 / 2″ |
292 |
372 |
457 |
542 |
627 |
|
POS |
NUMBER |
DESCRIPTION |
MATERIAL |
CERTIFICATE |
|
1 |
2 |
Nipple BSP Female |
EN 10204 3.1B |
|
|
2 |
1 |
Housing sch 40 s |
EN 10204 3.1B |
|
|
3 |
Spiral shaped element |
EN 10204 2.2 |
